Forced Air Drying Oven, LCD screen, DOF A, B Series

Description


DOF-30-A DOF-70-A DOF-135-A DOF-225-A	DOF-430-B-DOF-430-A–DOF-625-A	DOF-625-B

Features
1. Horizontal and vertical forced air type,good temperature uniformity.
2. Microprocessor controller(with temperature correction and timing function), accurate and reliable.
3. Large LCD screen display.
4. High quality stainless steel chamber, removable shelf, easy-to-clean.
5. Silicon sealing ring for reliable sealing.
6. Leakage protection: When the equipment has leakage, the equipment will cut off its own power supply, which will not affect the normal operation of other equipment in the laboratory, and protect the safety of personnel and the laboratory.
7. Auxiliary temp. control: Dual temperature control system, which is more accurate and stable. Ensure that the equipment can control the temperature and operate normally when the main temperature controller is out of control.
8. Optional printer or RS485 interface which can print or connect computer for remote control and alarm.
9. Anti-hot handle
Technical Parameters:
1. Temp. Fluctuation:±1℃.
2. Temp. Uniformity:±2.5℃%.
3. Temp.Resolution:0.1℃
4. Timer:1~9999mins

Options:
1. Multi-segment programmable control
2. Built-in Printer
3. RS485 interface

Specifications

Model	DOF-30-A	DOF-70-A	DOF-135-A	DOF-225-A	DOF-430-A	DOF-625-A	DOF-430-B	DOF-625-B
Volume(L)	31.5	72	136	225	429	624	429	624
Chamber Size (W×D×H) cm	30×30×35	40×40×45	45×55×55	50×60×75	60×55×130	80×60×130	60×55×130	80×60×130
Exterior Size(W×D×H) cm	45×47×70	55×60×80	64×73×90	88×72×93	78×71×170	98×80×178	78×71×170	103×80×178
Package Size (W×D×H) cm	53×53×77	59×61×84	65×76×94	83×86×123	93×81×178	113×86×188	93×81×178	113×86×188
Power Rating(W)	700	1000	1600	2000	2600	3600	3500	5700
Temp. Range(℃)	RT+5～200						RT+5～300
Shelf	2/5	2/7	3/8	3/11	4/6	5/6	4/6	5/6
Net/Gross Weight(kg)	29/37	45/52	45/56	62/70	130/153	168/186	130/153	168/186
Power Supply	AC 220V 50Hz				AC 380V 50Hz		AC380V 50Hz
Shape	Vertical
