Portable Colorimete, SP-CLR200

Description

Colorimete

1. Leading Humanity Design and Convenient Operation

One-touch access to measurement interface

Structure design in line with ergonomics

East-to-use operating interface

2. Stable Measurement Performance

The repeatability △E is 0.08.

Portable structure design which is more conductive to keeping the instrument stable when using.

3. Convenient and Fast Locating

Illumination locating is a fast, simple and convenient locating which is created by us.

4. PC Software—Realizes More Function Expansion

Be able to perform color difference analysis, color difference cumulative analysis, chromaticity index, color sample database management, simulating object color, etc.

5. Advanced Power Management Design

SP-CLR200 battery can be repeatedly charged which will save cost. Meanwhile, it can measure more than 3000 times on one charge to ensure the stability of long time measurement.

Specifications

Model	SP-CLR200
Illuminating/Viewing Geometry	8/d
Measuring Aperture	Φ8mm
Detector	Silicon photoelectric diode
Color Space	CIELabCh* CIELab*, CIEXYZ
Color Difference Formula	ΔEab ΔLab ΔEC*h
Light Source	D65
Light Source Device	LED blue light excitation
Errors Between Each Equipment	≤0.50ΔE*ab
Storage	100pcs standards 20000pcs samples
Repeatability	Standard deviation within ΔE*ab 0.08 Average of 30 measurements of standard white plate
Net/ Gross Weight	1/2 kg
Dimension	20570100 mm
Packaging Size	360160300 mm
Power source	Rechargeable lithium-ion battery 3.7V@3200mAh
Lamp Life	3 years, more than 1 million measurements
Charging Time	2 hours (First time 8 hours–100% electricity)
Measurement Times Before Recharging	More than 3000 times
Operating Temperature/Humidity Range	-10~40℃, relative humidity 0~85% with no condensation
Data Interface	USB
Optional Accessory	Miniature thermal printer, Powder Test Box
