| Materials |
SS304 |
| Surface finishing |
Fine polishing |
| Function |
Eye and face washing |
| Switching ball valve |
Two-piece ball valve |
| Stainless steel dust cover |
Integrated cover, effective dust isolation |
| Pipe diameter |
38mm |
| Nominal pressure |
1.0Mpa |
| Working pressure |
0.2~0.4Mpa |
| Test pressure |
1.5Mpa |
| Working environment temperature |
0°C~40°C |
| Eye wash/face wash water flow |
≥11.4 L/min |
| Flow of eye wash |
≥1.5 L/min |
| Eye wash bowl |
300mm straight edge design, gather water, prevent splash |
| Dust cover |
Integrated design of main body, not easy to lose |
| Inner size |
Rp1” female |
| Outlet size |
Rp1” female |
| Inlet height |
1065mm |
| Outlet height |
90mm |
